I usually fly with a Saitek X55 and I had a backup Thrustmaster T-Flight but neither was available. There were Xbox 360 controllers lying around but I remembered having an Ace Combat 6 HORI Ace-Edge stick from the Xbox 360 Game. So why not try to make it work with Elite Dangerous?

• Ace Combat 6 Pc Game
• Ace Combat 6 Pc Port
• Ace Combat 6 Pc Screenshots

Ace Combat 6: Fires of Liberation (2007) was released for the Xbox 360, marking the series' debut on a Microsoft platform. It is the first Ace Combat title to implement online multiplayer and downloadable content, which have become staple inclusions since. Its story involves an invasion of the Republic of Emmeria by its neighbor, the Federal. ACE COMBAT™ ASSAULT HORIZON Enhanced Edition. All Discussions Screenshots Artwork Broadcasts Videos News Guides Reviews 17 in Group Chat. Ace Combat Assault Horizon Enhanced Edition Free Download mengambil latar belakang waktu pada tahun 2015-2016. Pada permainan ini, diceritakan bahwa sekelompok satuan tempur PBB ditugaskan untuk menangani pemberontakan yang terjadi di Afrika Timur.

Steps

1. Install the Xbox 360 controller drivers
2. Test the ACE Edge
3. Get USB the VID/PID
4. Add VID/PID to DeviceMappings.xml
5. Create a new Custom Control Profile

Ace Combat 6 Pc Game

Install the Xbox 360 controller drivers
Download the Xbox 360 controller drivers from Microsoft then install. A reboot may be necessary.
Test the ACE Edge
Run joy.cpl -> Properties -> Test. Move the stick and press all the buttons to test that you are getting inputs. The Throttle two knobs on the throttle are dummies. The button above LB is also false. M1/M2/M3 mode switches are not recognized by joy.cpl. Same with the Xbox button on the Stick body.
Axes
Joystick Buttons
Throttle Buttons
Get USB the VID/PID
We need to register the Vendor ID and Product ID of the Ace-Edge with ED. Run Control Panel -> Device Manager -> Microsoft Common Controller for Windows -> Xbox 360 Controller for Windows -> Details -> Property: Hardware IDs
It should return the above if you only have the Ace-Edge hooked up as a gamepad.

Add VID/PID to DeviceMappings.xml
Find your existing Custom*.binds and make backups in C:Users

Ace Combat 6 Pc Port

your user idAppDataLocalFrontier DevelopmentsElite DangerousOptionsBindings.ED currently comes in 32-bit (1.5), 64-bit (1.5) and 64-bit-only Horizons (2.02). There appears to be multiple directories where DeviceMappings.xml can be modified. But you only need to change the one you intend to play.
(Elite Dangerous Ships 1.5 and Horizons 2.02)

Ace Combat 6 Pc Screenshots

C:UsersAppDataLocalFrontier_DevelopmentsProductsFORC-FDEV-D-1002
Inside either of those is a ControlSchemes directory. Make a backup of DeviceMappings.xml. Modify DeviceMappings.xml then add the PID and VID to the Gamepad area. I put mine in the end of that section right before the Gamepad tag for the XB1 controller.
Don't forget to save! If you want a sample here is the posted code.
Create a new Custom Control Profile
Start Elite Dangerous. If you did the above right, the joystick D-pad should let you navigate the menu. The Trigger button (A) will work as select. From here you can go to Options -> Controls -> Xbox 360 Controller. From here you can start customizing as you desire.
I discovered that the Paddle didn't work well as yaw or thruster. When I tried to map it to Left/Right Thruster Axis it turned into a permanent right thrust/turn. Instead I treat it as a modifier button in combination with D-pad to provide left/right thrust. That's too bad since this was used as yaw in the AC6 game. By default the yaw is mapped to the R-Stick x axis.
The Throttle D-pad is supposed to mirror the Joystick D-pad but it wasn't reliable to trigger on my stick so I left it alone. The calibration on my throttle was also a bit suspect when running in full range. If I need a reverse switch I can use the index finger button on the throttle. Also the Joystick Start button couldn't be mapped to the game. It appears to be hard coded as an escape key.
I made an AceEdge.binds which can be used as a starting point. Just copy it to the ControlSchemes folder.Update:Found a thread on this in Frontier forums on Ace Edge Z-Rotation does not work.
